Compliance Information

• Legal Verification: None

Connections (Data Interface)

Dimensions

• Dimensions (W×D×H): 219 × 317 × 345 mm
• Weighing Chamber Height: 240 mm
• Weighing Pan Diameter: ⌀ 120 mm

Features

• Adjustment: Internal
• Anti-Theft Locking Device: Kensington Lock, lockdown capability for cable or chain
• Display: LED screen with touch technology
• Languages: English, German, France, Italian, Spanish, Portuguese, Russian, Polish
• Leveling: Manual
• Readability: 1 mg
• Repeatability: 1 mg
• Typical Stabilization Time: ≤1.0 s
• Underfloor Weighing: Yes

Operating Conditions

• Maximum Weighing Capacity: 620 g
• Operating Conditions - Temperature: +10 – +30 °C

Power Requirements

• Power Requirements: 100 – 240 VAC, ±10%, 50 – 60 Hz, 0.2 A
• Power Requirements (Secondary): 15 VDC, ±5%, 0.53 A

Product Information

• Packaging: 400 × 525 × 495 mm

Specifications

• Draft Shield: Manual
• External Calibration Weight: 500 g | F1
• Linearity: 2 mg
• Sensitivity Drift between +10 °C and +30 °C: ±2.0 ppm/K
• Weighing Units: Gram, kilogram, carat, pound, ounce, troy ounce, Hong Kong tael, Singapore tael, Taiwan tael, grain, pennyweights, milligram, parts per pound, China tael, mommes, Austrian carat, tola, baht, mesghal and Newton

Weights

• Gross Weight: 8.1 kg
• Net Weight, approximate: 6.3 kg
