- USB mains adaptor for PF‑12 / PF‑12Plus / PF‑3
-
Hazardous material: No CE certified: Yes Operating range: 10–40 °C, max. 80 % relative humidity (non-condensing) Warranty: 2 Years Update: Free via internet / PC Display: Backlit graphic display, 128 x 64 pixel Scope of delivery: Photometer, software DVD, manual, 4 batteries, 4 empty test tubes, funnel, beaker, syringe, USB cable, calibration cuvette, cleaning cloth and certificate in rugged case Type: Filter photometer with microprocessor control, self-test and auto-calibration Weight: 0.7 kg Data memory: 1000 results, GLP conform Language: DE / EN / FR / ES / IT / NL / HU / PL / PT / CZ / ID / SL / TR / MY Dimensions: 215 x 100 x 65 mm Interfaces: USB 2.0 Operation: Self-explanatory menu guidance, plastic foil keypad, test selection via parameter lists Power supply: Via USB power supply, standard or rechargeable batteries or accu-pack Light source: Xenon lamp Optical system: Automatic filter wheel with 7 interference filters Wavelength: 345 nm / 436 nm / 470 nm / 540 nm / 585 nm / 620 nm / 690 nm plus 1 compartment for an additional filter; 860 nm LED for NTU measurement Wavelength accuracy: ± 2 nm, bandwidth at half transmission 10 nm–12 nm Photometric range: ± 3 E Photometric accuracy: ± 1 % Measuring modes: More than 100 preprogrammed tests and special methods, absorbance, transmission, factor, standard, nephelometric turbidity measurement; 50 freely programmable methods Turbidity measurement: Nephelometric turbidity measurement at 860 nm (based on ISO 7027), 1–1000 NTU Cuvette slot: Round tubes 16 mm OD Long term stability: < 0.002 A/h External light: Insensitive to external light, fast measurements without cuvette slot cover Preprogrammed tests: NANOCOLOR tube tests, VISOCOLOR ECO tests and Powder Pillows Housing: Shock-resistant; waterproof and dustproof, according to IP 68 Auto off: Inactive or automatic shutdown after 5 min, 10 min, 15 min, 20 min, 60 min Internal quality control: With NANOCONTROL NANOCHECK 2.0 -
General Information:
NANOCOLOR Photometric tests
Photometry is the standard for analysis of water and wastewater samples in many industries and branches. International norms recommend photometry for water quality monitoring. MACHEREY‑NAGEL offers comfortable tube tests and standard tests for determination of various parameters in water samples.
Downloads:
NANOCOLOR analysis system (EN) Download Flyer (PDF)
