• Weighing

• Dosing

• Counting

• Percentage weighing

• Net total

• Totalizing

• Animal weighing

• Calculation

• Density

• Statistics

• Peakhold

• Checkweighing

• Mass unit conversion

• Underfloor weighing

Compliance Information

• Legal Verification: Legal Verification

Connections (Data Interface)

Dimensions

• Dimensions (W×D×H): 219 × 317 × 94 mm
• Weighing Pan Dimensions: 182 x 182 mm

Features

• Adjustment: Internal
• Anti-Theft Locking Device: Kensington Lock, lockdown capability for cable or chain
• Display: LED screen with touch technology
• Languages: English, German, France, Italian, Spanish, Portuguese, Russian, Polish
• Leveling: Manual
• Readability: 0.1 g
• Repeatability: 0.1 g
• Typical Stabilization Time: ≤0.9 s
• Underfloor Weighing: Yes

Operating Conditions

• Maximum Weighing Capacity: 2,200 g
• Operating Conditions - Temperature: +10 – +30 °C

Power Requirements

• Power Requirements: 100 – 240 VAC, ±10%, 50 – 60 Hz, 0.2 A
• Power Requirements (Secondary): 15 VDC, ±5%, 0.53 A

Product Information

• Packaging: 350 × 445 × 250 cm

Specifications

• Draft Shield: None
• External Calibration Weight: 2 kg | F2
• Linearity: 0.3 g
• Sensitivity Drift between +10 °C and +30 °C: ±2.0 ppm/K
• Weighing Units: Gram, kilogram, carat, pound, ounce, troy ounce, Hong Kong tael, Singapore tael, Taiwan tael, grain, pennyweights, milligram, parts per pound, China tael, mommes, Austrian carat, tola, baht, mesghal and Newton

Weights

• Gross Weight: 7.0 kg
• Net Weight, approximate: 6.2 kg
